interface : RS-232C,USB2.0

bluetooth (optional) 1 class bluetooth,Ver.2.1 +EDR,Transmission distance radius:300m*9

others

laser designator Coaxial EDM red laser beam

Guiding light Green laser diode(524nm)and red laser diode(626nm),Job scope1.3~150m*2

level Circular bubble ±6′(inside circle)

Long level :10′/2mm

Laser alignment device (optional) 2 class laser product,red laser diode(635nm±10nm),alignment accuracy:<1.0mm/1.3m

Optical to implement magnification:3X,shortest focus:0.3m from base

Dust/waterproof IP65

Working temperature -30~+60℃

sise(including carrying handle) dual platen:191mm(W)×190mm(L)×348mm(H)

Weight(including carrying handle and battery) 5.7kg

power system

Bettery BDC70 Onboard battery Rechargeable lithium batteries

Working time (angular distance) BDC70 about 20 hours

BT-73Qexternal, selected) about 49 hours

 Please contact us for more information about this product.
